Product facts
Size: 30 × 30 cm
Finish: Transparent, high-gloss paint protection film
Product: Solar Gard Clearshield® Pro ACTIV™
Use: For wheel arches, vulnerable painted surfaces such as door sills, boot loading edges, door edges and smaller bodywork parts
SOLAR GARD® · PREMIUM PAINT PROTECTION FILM
Clearshield® Pro ACTIV™
Self-healing paint protection film that works instantly.
Clearshield® Pro ACTIV™ is an advanced, transparent paint protection film from Solar Gard. The film creates an almost invisible protective barrier over the vehicle’s original paint and helps protect against stone chips, fine scratches, dirt, insects and everyday wear.
The best protection you will never see
Invisible protection.
Active performance.
The active self-healing technology reacts to fine scratches and superficial marks without the need to apply heat or hot water.
200 µm
Total film thickness
SPF 285+
Protection against UV damage
10 years
Limited warranty*
Protection designed to stay almost invisible
Developed for the paint you want to preserve
Active self-healing
Advanced polymer technology reacts immediately to fine scratches and superficial marks. No additional heat is required to start the process.
Hydrophobic, dirt-repellent surface
The cross-linked topcoat causes water to bead and helps repel road grime, insects, bird droppings and other contaminants.
Glossy premium finish
High optical clarity and a glossy surface allow the vehicle’s colour to shine through and help maintain a well-cared-for, freshly waxed appearance.
Protection for the vehicle’s value
The transparent protective barrier helps preserve the original paint and the vehicle’s overall appearance, both during ownership and for a future sale.
Technical data
Performance in every layer
| Total product thickness |
200 µm |
| TPU thickness |
150 µm |
| Elongation at break |
> 250% |
| Gloss, ASTM D523 |
92 GU |
| Stone-chip test, SAE J400 |
Passed |
| Self-healing in laboratory test |
< 1 minute** |
Installation
The foundation of a premium result
1. Work in a clean, dust-controlled environment at a temperature above 10 °C.
2. Thoroughly clean, degrease and decontaminate the paint. The surface must be free from wax, dirt and fibres.
3. The product has both a protective cap sheet on the top surface and a liner on the adhesive side. Both must be removed during installation.
4. Wet-apply and position the film, then work the installation solution outwards from the centre towards the edges.
5. Dry and inspect the surface carefully. Seal the edges thoroughly to help prevent water and dirt from getting underneath the film.
Documentation & support
See the technology and installation
Read Solar Gard’s official product sheet with installation guide and technical data, or watch the videos for a clearer overview of the product and installation process.
Premium solutions · Engineered to perform
Protect the paint before damage occurs
Clearshield® Pro ACTIV™ gives the vehicle’s most exposed painted surfaces durable, almost invisible protection without changing its colour or appearance.
Learn more about Clearshield®
* The warranty is subject to Solar Gard’s current warranty, product and installation terms. ** The stated self-healing result is based on Solar Gard’s laboratory test using a brass brush. Actual results may vary depending on factors including scratch depth, temperature and environmental conditions.
